Introduction to FoundationDB

Currently, we can run FoundationDB from the official Docker mirror published by CI: https://hub.docker.com/r/foundationdb/foundationdb

(There’s a lot of other interesting stuff there, too.)

docker run -d foundationdb/foundationdb

This image comes with many default configurations that save time. Then, if we want to access the container:

docker exec -it fdb bash

Now run:

fdbcli

to open the FoundationDB command-line interface.

You can explicitly point to the cluster file inside the container:

fdbcli -C /var/fdb/fdb.cluster

Check the status and see whether it already comes with a database or not — it might say unavailable.

Note: The cluster file is how clients and servers discover the cluster.

By default, it lives in /etc/foundationdb/fdb.cluster on Linux; inside the container it’s usually at /var/fdb/fdb.cluster.

Copying that file is how you add new clients or hosts to the cluster — it should not be manually edited except for coordination purposes.

Creating a Database

If there’s no database, refer to the documentation:

(Re)creating a database

Installing FoundationDB packages usually creates a new database automatically.

However, if a cluster does not have a database configured (e.g., installation failed, data was deleted, or packages weren’t used),

you can manually create it with configure new in fdbcli:

configure new single memory

This command creates a new database ready to use.

Note that package installations — and Docker mirrors — may not include a pre-created database, so it’s best to do it yourself since the default data is usually just for testing.

Checking Contents

You can’t query how many databases or tables exist, like SELECT * FROM table-name,

because FoundationDB is not a relational database — it has no tables.

It’s an Ordered Key-Value Store (OKVS).

All data lives in a single global key-value namespace.

In fdbcli:

getrangekeys "" \xff

This iterates from "" up to "\xff" — the typical upper bound of the user keyspace.

Optionally, you can append LIMIT 50.

Note: When querying in fdbcli, use double quotes ("") instead of single quotes.

Single quotes are not special characters and will not work properly.

FoundationDB Philosophy

FoundationDB doesn’t come with ready-made tables or a dashboard admin panel.

It’s pure infrastructure — think of it like a kernel.

If you don’t mount anything on top, it doesn’t do much beyond handling get and set operations.

The beauty lies in the fact that from here, you can choose what layer to build above it — even entire distributed systems.

Comparison Matrix

(placeholder for blog table or chart) https://en.wikipedia.org/wiki/Ordered_key–value_store

Pure OKVS (LMDB, RocksDB, LevelDB, Kyoto, BerkeleyDB, WiredTiger, etc.)

• Embedded libraries designed to run inside a single process.
• Provide basic operations: put, get, range, and sometimes local transactions.
• Example use cases:
  • LevelDB in Chrome for caching
  • RocksDB in Kafka Streams
  • LMDB in OpenLDAP

Distributed OKVS (FoundationDB, TiKV)

• Not just libraries — full clusters with consensus, replication, sharding, and failover.
• Expose the same KV API but guarantee cluster-wide ACID transactions.
• FoundationDB uses a deterministic design with a centralized transaction log for serializing commits.
• TiKV implements the Spanner/Percolator model (MVCC + Raft).

Higher-Level Distributed Databases

(Cassandra, Spanner, Aurora, Bigtable, etc.)

• No longer expose raw KV APIs — they provide full SQL/NoSQL services.
• Some (Aurora, PostgreSQL, MySQL, Oracle, Percona, etc.) are traditional RDBMS with replication mechanisms.
• Others (Cassandra, Bigtable, MongoDB, Redis) are NoSQL systems with different consistency models.
• FoundationDB sits below these — it doesn’t offer SQL queries, but provides the transactional substrate you could build one on top of (e.g., Record Layer).

Collateral Infrastructure

(BookKeeper, S3/MinIO, ElasticSearch, MeiliSearch)

• Not core databases but specialized components:
  • Durable logs
  • Object storage
  • Search engines
• Yet they all share the same underlying pattern: data persistence with varying APIs and consistency models.

Value-Added Layers

(Record Layer, DeepSeek 3FS, Snowflake FrostDB, Adobe Identity Graph, eBay NuGraph — all built on FDB, though rarely acknowledged)

• Use a transactional KV substrate as a reliable foundation to implement high-level features:
  • SQL engines
  • Document stores
  • Streams
  • Machine learning datasets
• The clearest example is FoundationDB + Record Layer — Apple built CloudKit entirely on top of it.

Final Note

New technologies keep emerging — TigrisData, Neon, FaRM, FastACS, Yugabyte, ScyllaDB, TigerBeetle…

FoundationDB is not NoSQL, not NewSQL —

it is the distributed storage kernel.
