FDB + MinIO: Metadata (Java)

We’ll build a small HTTP service that registers and retrieves blob metadata stored in MinIO.

The raw bytes live in MinIO; FoundationDB stores the metadata catalog — owner/tenant, bucket, object key, size, hash, timestamps, tags, etc.

Goal: a minimal MVP to later iterate toward advanced idempotency, presigned URLs, and composition with other SNAPs, etc.

1. Local Infrastructure (docker-compose)

We’ll create a docker-compose.yml for our three base services.

version: "3.8"

services:
  fdb:
    image: foundationdb/foundationdb:7.4.0
    container_name: fdb
    command: >
      fdbserver
      --listen_address 0.0.0.0:4500
      --public_address fdb:4500
      --cluster_file /var/fdb/fdb.cluster
      --datadir /var/fdb/data
      --logdir /var/fdb/logs
    volumes:
      - fdb-data:/var/fdb/data
      - ./fdb.cluster:/var/fdb/fdb.cluster:ro
    ports:
      - "4500:4500"
    restart: unless-stopped

  minio:
    image: minio/minio
    container_name: minio
    environment:
      MINIO_ROOT_USER: minio
      MINIO_ROOT_PASSWORD: minio12345
    command: server /data --console-address ":9001"
    ports:
      - "9000:9000"
      - "9001:9001"
    volumes:
      - minio-data:/data
    restart: unless-stopped

  app:
    build:
      context: .
      dockerfile: docker/Dockerfile
    container_name: meta-app
    depends_on:
      - fdb
      - minio
    environment:
      MINIO_ENDPOINT: http://minio:9000
      MINIO_ACCESS_KEY: minio
      MINIO_SECRET_KEY: minio12345
      FDB_CLUSTER_FILE: /etc/foundationdb/fdb.cluster
    volumes:
      - ./fdb.cluster:/etc/foundationdb/fdb.cluster:ro
    ports:
      - "8080:8080"
    restart: unless-stopped

volumes:
  fdb-data:
  minio-data:

To obtain the cluster file for the Java client:

docker cp fdb:/var/fdb/fdb.cluster ./fdb.cluster

2. Key Schema in FDB (Tuple Layer)

Root: ("b")

("b", tenant, objId, "meta")  -> JSON { bucket, object, size, sha256, contentType, etag, createdAt, tags: {k:v} }
("b", tenant, objId, "state") -> BYTE (0=pending, 1=committed)

For the MVP, we’ll only write meta and state=1.

Later, you can add prefix indexes, tags, or owner-based lookups.

Conventions

• tenant: short string (e.g. "acme")
• objId: logical identifier within tenant (UUIDv7 recommended)

3. Minimal API (Javalin)

PUT /o/{tenant}/{id}

Registers or updates metadata for an existing MinIO object.

Body JSON:

{
  "bucket": "metas",
  "object": "imgs/networking.png",
  "contentType": "image/png",
  "size": 12345,
  "sha256": "...",
  "tags": { "owner": "you or me", "kind": "img" }
}

Validates object existence in MinIO (via statObject)

→ stores meta + state=1 in FDB (transaction).

Idempotent per (tenant, id).

GET /o/{tenant}/{id}

Returns JSON metadata.

HEAD /o/{tenant}/{id}

Returns 200 if exists, 404 if not.

GET /o/{tenant}?prefix=abc

Lists object IDs starting with prefix abc (range scan).

MVP: fixed limit (e.g. 100).

DELETE /o/{tenant}/{id}?deleteBlob=true|false

Deletes metadata; if deleteBlob=true, also attempts MinIO deletion.

4. Java Project (Gradle)

plugins {
    id 'java'
    id 'application'
    id 'com.github.johnrengelman.shadow' version '8.1.1'
}

group = 'org.fmartinez'
version = '1.0-SNAPSHOT'

repositories { mavenCentral() }

java { toolchain { languageVersion = JavaLanguageVersion.of(21) } } // 21 LTS

dependencies {
    implementation "org.foundationdb:fdb-java:7.4.3"
    implementation "io.minio:minio:8.6.0"
    implementation "io.javalin:javalin:6.7.0"
    implementation "com.fasterxml.jackson.core:jackson-databind:2.20.0"
    runtimeOnly   "org.slf4j:slf4j-simple:2.0.16"

    testImplementation platform('org.junit:junit-bom:5.10.0')
    testImplementation 'org.junit.jupiter:junit-jupiter'
    testRuntimeOnly 'org.junit.platform:junit-platform-launcher'
}

application {
    mainClass = 'Server'
}

tasks.test { useJUnitPlatform() }

Repository: https://github.com/fmartinez09/metadata

5. Containerization (Docker)

Why?

The Java binding requires the native FoundationDB client installed on the host (or in PATH/LD_LIBRARY_PATH).

On Windows, it tries to load fdb_java.dll (JNI) from the JAR and then fdb_c.dll from the system.

As of 7.4.x, the published Maven JAR does not include fdb_java.dll for Windows, so we must run it in Linux (Docker image with JDK).

We’ll create a multi-stage Dockerfile using JDK 24 + foundationdb-clients 7.4, connecting to FDB and MinIO over Docker network (avoiding DLL headaches).

# --- Build stage: compile and create fat-jar ---
FROM gradle:8.9-jdk21 AS build
WORKDIR /app
COPY . ./
RUN gradle shadowJar -x test

# --- FDB stage: extract libfdb_c.so ---
FROM foundationdb/foundationdb:7.4.0 AS fdb

# --- Runtime stage: JRE + libfdb_c.so copied ---
FROM eclipse-temurin:21-jre

COPY --from=fdb /usr/lib/libfdb_c.so /usr/lib/libfdb_c.so

ENV MINIO_ENDPOINT=http://minio:9000 \
    MINIO_ACCESS_KEY=minio \
    MINIO_SECRET_KEY=minio12345 \
    FDB_CLUSTER_FILE=/etc/foundationdb/fdb.cluster

COPY --from=build /app/build/libs/*-all.jar /app/app.jar
COPY docker/entrypoint.sh /entrypoint.sh
RUN chmod +x /entrypoint.sh && mkdir -p /etc/foundationdb

EXPOSE 8080
ENTRYPOINT ["/entrypoint.sh"]

entrypoint.sh

This script automates startup tasks. It ensures that the Java app has access to the fdb.cluster file.

Steps:

1. Check if /etc/foundationdb/fdb.cluster exists.
2. If not, create it with the line docker:docker@fdb:4500.
3. Print its contents.
4. Launch the app (java -jar /app/app.jar).

#!/usr/bin/env bash
set -euo pipefail

if [ ! -f "${FDB_CLUSTER_FILE}" ]; then
  echo "docker:docker@fdb:4500" > "${FDB_CLUSTER_FILE}"
fi

echo "Using FDB_CLUSTER_FILE at ${FDB_CLUSTER_FILE}:"
cat "${FDB_CLUSTER_FILE}" || true

echo "Starting app..."
exec java -jar /app/app.jar

⚠️ Notes:

• Requires the FDB_CLUSTER_FILE variable (because of set -u).
• Doesn’t overwrite an existing file.
• The JAR must be self-contained (ShadowJar or Spring Boot fat-jar).

Directory Layout

metadata/                 # Gradle project root
├── build.gradle
├── settings.gradle
├── src/
│   └── main/java/...      # Server.java, FdbStore.java, etc.
├── fdb.cluster            # shared cluster file (1 line: docker:docker@fdb:4500)
├── docker/
│   ├── Dockerfile
│   ├── entrypoint.sh
├── docker-compose.yml

6. Build the Image (generates fat-jar in build stage)

Create fdb.cluster:

PowerShell:

"docker:docker@fdb:4500" | Out-File -NoNewline -Encoding ascii .\fdb.cluster

Bash:

echo docker:docker@fdb:4500 > fdb.cluster

Build:

docker compose build

Run:

docker compose up -d

Check app logs (confirm cluster file loaded):

docker compose logs -f app

7. Initialize the FDB Database (first time only)

FoundationDB starts but the cluster is initially “unconfigured”.

docker compose exec fdb fdbcli --cluster_file /var/fdb/fdb.cluster --exec "configure new single ssd"
docker compose exec fdb fdbcli --cluster_file /var/fdb/fdb.cluster --exec "status minimal"

Once you see Database available, you’re ready.

8. Create the MinIO Bucket (once)

The service validates object existence in MinIO, so we need a bucket.

You can create it via the web console (http://localhost:9001, user: minio, pass: minio12345)

or using the mc client:

mc alias set local http://localhost:9000 minio minio12345
mc mb local/metadata
mc ls local

9. Register Metadata in FDB

Access FDB:

docker compose exec fdb fdbcli --cluster_file /var/fdb/fdb.cluster

To inspect key ranges:

getrangekeys "" \xff

PUT

$body = @{
  bucket="metadata";
  object="networking.jpg";
  size=(Get-Item .\networking.jpg).Length;
  sha256="DF47E064EFC7A9ABC31E3E556BC0E43CF933738D4C843D9F41139194F28638EC";
  contentType="image/jpeg";
  tags=@{ owner="fernando"; tipo="foto" }
} | ConvertTo-Json -Depth 3

Invoke-RestMethod -Method PUT -Uri "http://localhost:8080/o/tenant1/foto-001" -ContentType "application/json" -Body $body

GET (read metadata)

Invoke-RestMethod -Method GET -Uri "http://localhost:8080/o/tenant1/foto-001"

HEAD (check existence)

$resp = Invoke-WebRequest -Method HEAD -Uri "http://localhost:8080/o/tenant1/foto-001"; $resp.StatusCode  # 200 or 404

LIST (IDs per tenant)

Invoke-RestMethod -Method GET -Uri "http://localhost:8080/o/tenant1"

DELETE (metadata only)

Invoke-RestMethod -Method DELETE -Uri "http://localhost:8080/o/tenant1/foto-001" -SkipHttpErrorCheck

DELETE (metadata + blob in MinIO)

Invoke-RestMethod -Method DELETE -Uri "http://localhost:8080/o/tenant1/foto-001?deleteBlob=true" -SkipHttpErrorCheck

✅ Done. You’re working with the most powerful database on the market.

To clean everything up:

docker compose down -v
